Introduction

If your GameSir Nova 2 Lite controller’s bumpers are unresponsive, sticky, or broken, this guide will help you replace them and restore full functionality. Over time, the bumpers can wear out due to frequent use, accidental drops, or internal component damage.

Before you begin, make sure to power off the controller and disconnect it from any devices to avoid accidental shocks or damage during the repair.

What you need

Step 1 Battery

GameSir Nova 2 Lite Bumper Replacement, Battery: step 1, image 1 of 2

GameSir Nova 2 Lite Bumper Replacement, Battery: step 1, image 2 of 2

Before you take your controller apart make sure it is powered off by holding the power button down for 15 seconds until it stops blinking.
Use a Phillips #0 screwdriver to remove the four 8.5 mm screws from the bottom of the controller's casing.

Edit

Step 2

GameSir Nova 2 Lite Bumper Replacement: step 2, image 3 of 3

Insert an opening tool between the two halves to open the controller's casing.
You will feel several internal latches called “snap-fit connectors.”
Disconnect them by sliding the opening tool along the seam in the casing, applying continuous pressure.
Once you find a connector, apply increased pressure until you hear a snapping sound.
Repeat this process until all of the connectors are disconnected.
Separate the top and bottom of the controller case.

Edit

Step 3

Set aside the bottom half of the shell.
Position the controller so that the motherboard is visible.
Use the point of a spudger to push on alternating sides of the battery connector to "walk" it out of its socket.
If that doesn't work, use a pair of tweezers to firmly grip the sides of the connector and pull straight away from the socket. Hold the tweezers closer to the connector to get a better grip.

Edit

Step 4

If the battery appears swollen follow this link.
The battery is held in place by double-sided adhesive.
Use a spudger to loosen the tape securing the battery.
Remove the battery from the controller.

Edit

Step 5 Rumble Motor

GameSir Nova 2 Lite Bumper Replacement, Rumble Motor: step 5, image 1 of 2

GameSir Nova 2 Lite Bumper Replacement, Rumble Motor: step 5, image 2 of 2

Push on alternating sides of the JST connector to release it from the socket on the circuit board.
If that doesn't work, use a pair of tweezers to firmly grip the sides of the connector and pull straight away from the socket. Hold the tweezers closer to the connector to get a better grip.
